Size Customization
360 view angle
Model(mm): P4.8，P5，P6 ，P8 ，P10
Diameter(m)：2，2.5，3，4，5，6，8，11
Diameter, model, etc. can be customized
Patented products pioneered by peers
Excellent quality, leading technology
Many large application cases
Museums, Planetariums, Science and technology museums, Children’s palaces, Exhibition halls, Gymnasiums, Waiting halls, Hotels, Large open-air places, Railway stations, Ports, Shopping malls, Bars, etc.
According to the design plan, make the steel structure for the shell of the spherical screen. The shell is usually made of metal material and has characteristics such as waterproof, dustproof, and earthquake resistance.
Install the LED module onto the surface of the casing steel structure and connect it to the power supply and control system. Then debug to ensure the normal operation and display effect of the LED spherical screen
Ensure lighting for 72 hours
Install the assembled spherical screen in the designated position and perform debugging. Debugging includes adjusting parameters such as brightness, color, and display effects to ensure the normal operation of the spherical screen.
First one design in led screen industry , get new record for shenzhen enterprises.
Max diameter 17m and other 16.3m 14m 1lm 8m7.2m 6m 5m
Not lighting up is also a beautiful sight
Customizable pixel pitch and diameter
High impact visual, good eye-catching
High qualitu LED beads, high brush IC, power supply
Customized PCB design with seamless splicing, tolerance 0.2mm
Waterproof, moisture-proof, dust-proof, sun-proof, cold-resistant
| Outdoor | |||||
| Model | P4.8 | P5 | P6 | P8 | P10 |
| Pixel Pitch(mm) | 4.8 | 5 | 6 | 8 | 10 |
| Diameter(m) | 2, 4 | 2.5 | 2，3 | 5 | 2，6，8,11 |
| LED Type | SMD1515 | SMD1515 | SMD1921 | SMD2727 | SMD3535 |
| Pixel Density(dots/m2) | 43402 | 40000 | 27777 | 15625 | 10000 |
| Brightness(cd/m2) | 5000 | 5000 | 5000 | 5000 | 7500 |
| Avg Power Consumption(W/m2) | 400 | 400 | 350 | 260 | 450 |
| Max Power Consumption(W/m2) | 1000 | 1000 | 800 | 650 | 1100 |
| Refresh Rate(Hz) | 1,920-3,840 | ||||
| Input Voltage | AC100-240V/50-60Hz | ||||
| Life Span | 100,000 hours | ||||
| Working Temperature | -20°C～60°C | ||||
| Working Humidity(RH) | 10%～90% | ||||
| Gray Scale | 12-16 bit | ||||
0
· Product: P5
· Screen Size: φ2.5m
· Location: Chongqing, China
0
· Product: P5
· Screen Size: φ2.5m
· Location: Jerusalem, Israel
0
· Product: P4
· Screen Size: φ2.5m
· Location: Zhejiang, China
